CS FLUIDPOWER 5/2-way solenoid valve CS-D2-D

• Flexible Control Options: Supports both Internal and External Pilot-oriented modes to adapt to diverse pneumatic system layouts.
• High-Responsiveness Structure: Engineered with a Sliding Column Mode design, delivering superior leak-tightness and ultra-sensitive switching reaction.
• Versatile Center Functions: 3-Position solenoid valves offer three types of central functions (Closed, Exhaust, and Pressure Center) to suit your precise machinery needs.
• Dual-Control Memory: Double-control configuration includes an integrated memory function to securely maintain status under brief pulses.
• Ultra-Low Friction & Long Lifecycle: The internal bore is finished with an advanced precision processing technology. This achieves minimal attrition friction, a low startup pressure rating, and an extended operational service life.
• Maintenance-Free Design: Internally lubricated for lifetime performance — no need to add extra oil or mist lubrication during daily operations.
• Space-Saving Integration: Easily mounts onto centralized manifold bases to create integrated valve groups, drastically cutting down machine installation footprints.
• Effortless On-Site Debugging: Equipped with auxiliary manual override buttons to facilitate safe manual testing, easy installation, and streamlined troubleshooting.
• Global Voltage Compatibility: Multiple standard operating voltage grades are optional (including DC24V DC12V, AC220V, AC110V) to match localized electrical grids.

     Single solenoid 5/2 way                                               Double solenoid 5/2 way

Coil specification
220VAC 50/60Hz 3.5/2.6VA
110VDC 2.8W
100VAC 50/60Hz 3.2/2.6VA
110VAC 50/60Hz 4.4/3.3VA
120VAC 60Hz 4.4VA
48VDC  2.4W
24VDC  4.2W
12VDC  4.2W

Scope of voltage
AC: ±15%
DC: ±10%

Specification
Operating pressure:0.15~0.8MPa(21~114psi)
Temperature:-20~70℃
Material of body:Aluminum alloy
Fluid:Air(to be filtered by 40 µm filter element)
Acting:Internal pilot or external pilot
